ARMOR AR-509FIP3B-W (3.6mm) (3MP) HD Bullet IP Camera

ARMOR AR-509FIP3B-W (3.6mm) (3MP) HD Bullet IP Camera

The ARMOR AR-509FIP3B-W (3.6mm) (3MP) HD Bullet IP Camera is a high-definition surveillance camera designed for outdoor use. With its 3-megapixel resolution and 3.6mm lens, it provides clear and detailed images, making it suitable for monitoring large areas. The bullet design offers a sturdy and weatherproof construction, ensuring durability in various environmental conditions. Additionally, as an IP camera, it can be easily integrated into existing network systems for remote monitoring and management. Overall, the ARMOR AR-509FIP3B-W (3.6mm) (3MP) HD Bullet IP Camera is a reliable and effective solution for outdoor security surveillance needs.

Categories: ,

Description

General

Brand
ARMOR
Model
ARMOR AR-509FIP3B-W
Usage
Indoor
Type
Bullet IP Camera

Camera

Camera Type
Fixed
Mega Pixels
3.0MP
Max. Camera Resolution
2048 x 1536
Image Sensor
GC2083
Resolution
2048 x 1536/ 1920 x 1080/ 1280 x 720
Shutter Speed
PAL1/1-1/10000Sec; NTSC 1/1-1/10000Sec (Auto)
Day & Night
Full Color
Night Vision
Yes
S/N Ratio
>=52dB

Lens

Lens
Fixed Lens
Focal Length
3.6mm


General Function
Saturation/Brightness/Contrast /Sharpness, Mirror, 3DNR , WhiteBalance, BLC, FLK(Flicker Control)
Dual-Stream
Yes
Triple-Stream
No
Frame Rate
25Fps
Digital Noise Reduction (DNR)
3D NR
Wide Dynamic Range (WDR)
DWDR

Network & Connectivity

Interface(s)
RJ-45 (10/100M)
Wi-Fi
No
Wi-Fi Details
No
Wi-Fi Pairing
No

Security

Password Protection
Yes
Motion Detection
Yes
Human Detection
Yes
Face Detection
Yes
Lightning Protection
Yes

Technical Info

Video Type
H.264/H.265
Mic & Speaker
No
Audio Communication
G.711
Input Trigger
Motion Detection
Working Distance
25 Meter
Protocols
HTTP, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IPFilter, PPPOE, DDNS, IPSearch
Supported Operating System
Android, AndroidPad, iPhone, iPad

Physical Description

Form-Factor
Bullet
Card Slot
No
Storage Type
No
Body Material
Plastic
Color
White
Dimensions
102 x 82mm
Weight (gm)
500 gm

Power

Power
12V DC +-10%, 1000mA
Operating Temperature
-1 Degree C – +50 Degree C
Storage Temperature
-20 Degree C – +60 Degree C

Warranty

Warranty Details
1 Year (Without Adapter)

Additional Info

Others
Main processor: FH8852V200, TV System: PAL/NTSC, Sub-stream: 704*576/640*360/320*240 UsableIllumination 0.001Lux Video Output: Network, VideoDelay: 0.3S (WithintheLan), Recording Mode: NVR/NAS/CMS/Web, Language: ChineseSimplified, ChineseTraditional, English, Bulgarian, Polish, Farsi, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian, Infrared LED: 2PCSSMTLED, IR Status: Under10 Lux By CDS, IR Power On: CDS Auto Control.
Specialty
ONVIF2.4/ Hikvision (Protocol optional), P2P, POE, Privacy Masking 3 RectangularZone, IR Cut Filter.
Country Of Origin
Singapore
Made in/ Assemble
China
